Closed Top Mini Frac Tank are routinely used by a variety of industries for bulk storage of water, oil, chemicals, and other liquids or solids. Construction and pipeline companies, refineries, environmental organizations, manufacturing units, and agricultural establishments often rent frac tanks for their liquid storage needs.
Our Closed Top Mini Frac Tank is among the most advanced in the industry and we ensure that they are delivered to you in good condition. It’s not without reason that a company that started with just a few tanks now has a nationwide presence and an enviable inventory with hundreds of tanks at our disposal.
Closed Top Mini Frac Tank which can be used for large scale storage of hazardous and non-hazardous fluids such as transformer oil (T oil), fuel or water, waste containment, and a host of other applications. These closed top mini frac tanks have many key features that can be best placed into industrial safety and mechanical categories. These Closed Top Mini Frac Tank can be used in universities, construction sites, manufacturing industries, oil drilling, waste management, and other sites
Closed Top Mini Frac Tank Measurements:
Capacity: 8,400 gal (200 bbl)
Height: 8′ 6″
Width: 8′ 6″
Length: 24′
Tare Weight: 10,000 lbs
Closed Top Mini Frac Tank Mechanical Features:
- Bare steel interior
- 3″ fill line
- Three (3) standard 22″ side-hinged manways
- Multiple 4″ valved fill/drain ports, including floor-level
valves for low point drain out - JT-8 inch Pressure Relief Valve/16 oz Pressure/
0.4 oz Vacuum - Epoxy coated interior
- Two (2) top connection ports for vapor recovery
- Easy-to-clean design with smooth-wall interior, no
corrugations and no internal rods - Front-mounted ladder well for top access
- Smaller footprint for space saving on tight sites
- Roll-off truck compatible
Closed Top Mini Frac Tank Safety Features:
- Non-slip step materials on ladder wells and catwalks
- “Safety yellow” rails and catwalks for high visibility
- Safe operation reminder decals
Closed Top Mini Frac Tank Options:
- Steam coils
- Level gauge
- Steam coils
- White exterior for MSS compliance
- Audible alarms, strobes and level gauges
(digital and mechanical)
